The KYK ph adjustable alkaline water purifier is a trusted product. and received various awards Many from many countries such as Korea, the United States and Europe.
The name KYK comes from the initials of Dr. Kim Young Kwi, a famous scientist. Owner of up to 80 patents
Based on research on the science of human health for over 30 years, KYK products are outstanding in terms of inventing new things. and design a beautiful appearance It has become a unique combination of simplicity and luxury for today’s homes. The best alkaline water generator
Acid/Alkalinity (pH) Monitoring System
- Check pH/alkalinity control According to the needs of various applications, the ORP (antioxidant) value can be adjusted.
- Oxidizing and Deoxidizing power can be selected as needed.
Lifestyle Series works with a touch screen system. and a working sound
- Available in many colors Helps to enhance the atmosphere of the home or office.
- Languages available: English, Chinese or Korean.
Intelligent SMPS Electronic Control System
- The machine works quietly, not hot and saves electricity.
- It uses platinum-coated titanium electrodes sized 150 to 200 square inches.
High quality electrode pads with extra large contact size.
- Helps the process of ionization (ionization) to be effective.
- Helps work with precision, consistency and durability.
There is a cleaning system. and self-diagnostic system
- The intelligent mechanism analyzes and solves the problem when it crashes.
- Advanced 13-stage water filtration and production system (with a countdown sensor to tell you how much water is left for the filter)
- Removes particles, rust and dust with a multi-layer sediment filter.
- Removes chlorine, odors, pesticides and other organic substances. with carbon filter layer
- Prevents bacterial growth with a silver mixed carbon filter layer.
- Adjust the taste with high quality fine carbon filter layer.
- high efficiency The single filter system has a lifespan of up to 6,000 liters of water production, or a dual filter system with a lifespan of filter #1 up to 6,000 liters. Filter #2 produces up to 9,000 liters of water.
Specification
Manufacturer ID/Product ID |
2213/07-667 |
product type |
single filter type (KYK HISHA) |
product type |
double filter type (KYK30000, KYK33000, KYKGEN II) |
size |
Width 280 mm. x Height 340 mm. x Thickness 150 mm. (KYK HISHA) |
size |
Width 340 mm. x Height 340 mm. x Thickness 150 mm.(KYK30000, KYK33000, KYKGEN II) |
weight |
KYK HISHA 3 kg. .; KYK30000, 3 kg.; KYK33000 3 kg.; KYKGEN II 3 kg. |
installation |
Place it vertically or install it on the wall. Connect directly to the general water supply pipe or the water pipe under the sink. |
LCD display
|
pH and ORP level display, 7 color display, water flow rate per minute, cleaning system Automatic self, buzzer, first and second filter service life display, analysis result code display self problem |
control method |
Controlled by touch sensors |
Adjustment range for acidity/alkalinity |
can be adjusted between pH 3.0 – Ph 10.2 (KYK HISHA) |
Adjustment range for acidity/alkalinity |
The value set by the manufacturer 4.0/4.5/5.0/5.5/7.0/8.5/9.0/9.5/10.0 (KYK30000, KYK33000, KYKGEN II) |
ORP (Antioxidant) Adjustment Range |
Manufacturer preset from +790 to -460 (-700). |
Electrolysis
How electrolysis works |
Continuous-run electrolysis using water flow sensors |
Electrolysis capability |
Can set 4 levels of alkaline drinking water, 4 levels of acetic water and 1 level of neutral pH filtered water. |
Production capacity of alkaline and acidic water |
KYK HISHA Alkaline Water 1.5 L/min and Acetic Water 1.2 L/min |
Production capacity of alkaline and acidic water |
KYK30000 Alkaline water 2.0L/min and Acetic water 1.6L/min |
Production capacity of alkaline and acidic water |
KYK33000 Alkaline water 2.5L/min and Acetic water 2.0L/min |
Production capacity of alkaline and acidic water |
KYKGEN II Alkaline Water 2.5 L/min and Acetic Water 2.0 L/min |
electrolysis cell |
KYK HISHA Platinum Coated Titanium 90 Square Inch |
electrolysis cell |
KYK30000 170 square inch platinum coated titanium |
electrolysis cell |
KYK33000 240 square inch platinum coated titanium |
electrolysis cell |
KYKGEN II 240 square inch platinum coated titanium |
electrolysis power |
KYK HISHA SMPS @ 150 watts |
electrolysis power |
KYK30000 SMPS @ 180 watts |
electrolysis power |
KYK33000 SMPS @ 180 watts |
electrolysis power |
KYKGEN II SMPS @ 250 watts |
Cleaning the electrolysis plate |
automatically clear (Operated by Mycom) |
filtration system
Service life of KYK HISHA filter |
Single filter can filter up to 3000 liters. |
Filter service life KYK30000/KYK33000/KYKGEN II |
Filter 1 can filter up to 6000 liters. |
Filter service life KYK30000/KYK33000/KYKGEN II |
The second filter can filter up to 9000 liters. |
Filter material (Made in Korea) |
Filter 1: Antibacterial Filter, Zeomic Particles, Calcium Powder, Activated Carbon, Silver Powder sediment filter |
Filter material (Made in Korea) |
Filter 2: Anti-bacterial filter, activated carbon, activated carbon, silver powder |
Reminder system to change filters |
A warning message appears on the LCD when the filter reaches its end of life. But if the drinking water has an abnormal taste and smell The filter should be replaced immediately. |
Information about alkaline water filtration systems alkaline water filter adjust ph
adjustable temperature |
5 °C ~ 30 °C หรือ 41 °F ~ 86 °F |
water pressure |
1.5 ~ 3.0 kgf/cm2 |
electrical protection devices |
glass tube fuse |
electric current detection system |
The system stops the electrolytic cell automatically. |
Abnormal high temperature protection |
A temperature sensing device built into the SMPS will stop the unit when abnormally high temperatures are detected. |
